RESISTOR 1R 4W SBCHE41R0K

RESISTANCE, 4W 10% 1R
     Product Range: TE CONNECTIVITY - SBC Series
     Resistance: 1ohm
     Nominal Power: 4W
     Resistance Tolerance: ± 10%
     Resistance Type: Radially Loaded
     Type of Resistive Element: Rolled Conductor
     Temperature Coefficient: ± 400ppm / ° C
     Nominal Voltage: 2V
     External Width: 7.3mm
     Temperature coefficient. +: 400ppm / ° C
     Temperature coefficient. -: 400ppm / ° C
     Diameter of the conductor: 0.8mm
     External Length / Height: 20mm
     External Depth: 8.1mm
     Working Temperature Range: -55 ° C to + 250 ° C
     Resistance, Mounting: Through Hole
     Series: SBCHE4
     Temperature at Full Power: 70 ° C
     Max Working Temperature: 250 ° C
     Working Temperature Min .: -55 ° C
     Tolerance +: 10%
     Tolerance -: 10%
